E-Catalog > Bellow Expansion Joint Or Metal Joint:Metal pipe expansion joints > Covered Expansion Pipe Type

LARGE BORE INDUSTRIAL HOSE PH601 WATER SUCTION AND DISCHARGE HOSE W/P.10 BAR Application: Mandrel built heavy duty water suction and discharge hose for handling of water, inert fluid, sewerage, waste water, mud, etc., where optimum flexibility is required. Construction: Core: Synthetic rubber blended. Reinforcement: Plies of synthetic cords with helix wire. Cover: Synthetic rubber, wrapped typed, abrasion and weather resistant. Temperature Range: Continuous: -20°C to +85°C.

LARGE BORE INDUSTRIAL HOSE PH602 WATER DISCHARGE HOSE W/P.10 BAR. LAY FLAT Application: Light weight rubber hose design for water, natural liquid fertilizer, waste water, etc., for submerged pump and irrigation systems. Construction: Core: Synthetic rubber blended. Reinforcement: Plies of synthetic cords. Cover: Synthetic rubber blended. Temperature Range: Continuous: -20°C to +85°C.

LARGE BORE INDUSTRIAL HOSE PH624 SHOT BLASTING HOSE W/P.12 BAR Application: Suitably designed long lasting heavy duty hose for use in sand, metal grits and foundry waste with conductive rubber compound to ensure static electricity dissipation, abrasion loss of the tube according to ISO 4649: 50 ±5mm3. Construction: Core: Anti static Synthetic / Natural rubber blended. Reinforcement: 2 or 4 Plies of synthetic cords. Cover: Anti static Synthetic / Natural rubber blended, wrapped type, excellent abrasion resistant. Temperature Range: Continuous: -20°C to +80°C.

RUBBER STEAM HOSE PH472 STEAM 2 W/B HOSE - EPDM RUBBER RESISTANT HIGH TEMPERATURE STEAM Application: High temparature steam lines at constant pressure of 250 psi. Applicable Standard: Standard: IS 10655 Type 3/BS 5342. Construction: Core: EPDM rubber resistant high temperature steam Reinforcement: Double steel wire braids Cover: Black color, EPDM rubber resistant to abrasion, heat and weather Temperature Range: Upto +205°C

THERMOPLASTIC HYDRAULIC HOSE PH148 - SAE 100R7 / DIN EN855 MEDIUM PRESSURE HYDRAULIC LINES 70 TO 210 BAR Application: Medium Pressure Hydraulic Lines 70 to 210 bar. Suitable for Hydraulic application with increased resistance to abrasion. For use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural machinery, Earthmoving, Articulating & Telescopic booms and Material handling equipments. Can be used for industrial gases and other applications, please consult manufacturer. Applicable Standard: tandard: SAE 100 R7 / DIN EN 855 Construction: Core: Thermoplastic Elastomer Reinforcement: 1 braid of synthetic fibre Cover: Black color, Pin Pricked – Polyurethane. Available twin and multi lines with different hose combination and size. Also, special colors up on request. Temperature Range: Continuous: -40°C to +100°C Temp. not to exceed +70°C for Air and Water based fluids

HYDRAULIC HOSE PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

THERMOPLASTIC HYDRAULIC HOSE PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
