Product Information :
Name :
PU PNEUMATIC TUBE Category :
- เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
- Flexible Industrial Hose:Teflon Hoses,Flexible PVC
Brand :
ASHUN Product Type :
- วัตถุดิบ
- สินค้า, ผลิตภัณฑ์
Short Description :
PolyurethaneTube
● High flexibility
● Small bending radius
● Widely used in many applications
● Available in ether and ester types
● Optimum abrasion resistance
● High tensile strength
● Low temperature flexibility
Application
Automated machinery, coating machinery, all kinds of pneumatic tools, pneumatic & hydraulic machinery, construction and various pneumatic tools. Polyether based polyurethane tube is hydrolysis-resistant, anti-bacterial & anti-fungous, and it can be used for gardening, cleaning, water hoses and other purposes. Ether type polyurethane tube is resistance to hydrolysis, fungus and weatherability. Ester type polyurethane tube give maximum abrasion resistance and good oil, solvent and great resistance.
Product Detail :
PU PolyurethaneTube
● High flexibility ● Small bending radius
● Widely used in many applications
● Available in ether and ester types
● Optimum abrasion resistance
● High tensile strength
● Low temperature flexibility
Application
Automated machinery, coating machinery, all kinds of pneumatic tools, pneumatic & hydraulic machinery, construction and various pneumatic tools. Polyether based polyurethane tube is hydrolysis-resistant, anti-bacterial & anti-fungous, and it can be used for gardening, cleaning, water hoses and other purposes. Ether type polyurethane tube is resistance to hydrolysis, fungus and weatherability. Ester type polyurethane tube give maximum abrasion resistance and good oil, solvent and great resistance.
Description
| ITEM No. | OD | x | ID | x | Length (M) |
| (mm) | (mm) | ||||
| PU 0425 | 4.00 | x | 2.50 | x | 200 M |
| PU 0604 | 6.00 | x | 4.00 | x | 200 M |
| PU 0805 | 8.00 | x | 5.00 | x | 100 M |
| PU 09565 | 9.53 | x | 6.50 | x | 100 M |
| PU 1065 | 10.00 | x | 6.50 | x | 100 M |
| PU 1208 | 12.00 | x | 8.00 | x | 100 M |
| PU 1296 | 12.60 | x | 9.60 | x | 100 M |
Product Information
| Part No. | OD x ID | Burst Pressure (kgf/cm2) | Working Pressure (kgf/cm2) | Min. | Standard Length (M) | Weight |
| (mm) | Bending Radius (mm) | (g/M) | ||||
| PU 0425 | 4.00x2.50 | 32.0 | <10 | 10.0 | 100.20 | 9.00 |
| PU 0640 | 6.00x4.00 | 27.0 | <10 | 16.0 | 100.20 | 18.00 |
| PU 0850 | 8.00x5.00 | 32.0 | <10 | 22.0 | 100.00 | 38.00 |
| PU 09565 | 9.53x6.50 | 28.0 | <10 | 27.0 | 100.00 | 52.00 |
| PU 1065 | 10.00x6.50 | 30.0 | <10 | 28.0 | 100.00 | 55.00 |
| PU 1280 | 12.00x8.00 | 28.0 | <10 | 37.0 | 100.00 | 78.00 |
| PU 1296 | 12.60x9.60 | 30.0 | <10 | 39.0 | 100.00 | 82.00 |
