E-Catalog > Bellow Expansion Joint Or Metal Joint:Metal pipe expansion joints > Covered Expansion Capsule Type

Air Filter Regulator Lubricator ชุดปรับปรุงคุณภาพลมอัดหรือ ชุดกรองปรับลม?เพื่อใช้ในงาน ระบบลมอัด เพื่อกรองสิ่งสรกปรก ปรับแรงดันลมให้เหมาะสมกับการใช้งาน และ จ่ายน้ำมันให้กับระบบเพื่อหล่อลื่นสิ้นส่วนต่างในระบบลมอัด

PH534 - LPG HOSE AS PER EN 1762 : TYPE - D Applicable Standard : EN 1762 - Type D Application : Designed for transfer of LPG in liquid or gaseous phase and natural gas

PH611 - OIL / FUEL SUCTION & DISCHARGE HOSE W.P. 10 BAR Application : Mandrel built heavy duty oil suction and discharge hose for handling grades of gasoline or petroleum oils of aromatic content upto 50% from tank truck, in dispensing station etc, during winter/summer seasons and withstands full vacuum

PH703-04, paint hose Automation Grade: Manual Automation Grade : Manual Product Type : Paint hose Usage/Application : Paint application Material : spary hose Grade : paint Pressure : 520 bar Capacity : 7540 psi Air Flow Pattern : paint Maximum Hydraulic Pressure : 520 bar Fluid Pressure : Paint Fluids : paint The most popular airless hose size is 1/4" by 50 foot. Large sprayers may require 3/8". If you are running 100' of hose, it is best to start with 50-foot 3/8" at the sprayer then connect a 50'. Protect your hose with a disposable hose cover.

PH154 - SAE J517-100-R2 / EN 853 2SN HIGH PRESSURE HYDRAULIC LINES 80 TO 415 BAR Application: High Pressure Hydraulic Lines 80 to 415 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in Hydraulic systems Suitable for Agricultural, Earthmoving & Material handling equipments and machineries/systems. Applicable Standard: Standard: SAE J517 – 100 R2 / EN 853-2SN Construction: Core: Oil & water resistant Synthetic rubber Reinforcement: Double steel wire braids Cover: Black Color, Synthetic rubber resistant to weather and abrasion ,oil & ozone Temperature Range: Continuous: -40°C to +120°C Impulse Cycles : 200,000 Tested upto: 400,000 cycles,upto 1” I.D.

PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID Application: Airless paint spray systems for 120 to 350 bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases. Applicable Standard: Standard: Polyhose proprietary Hose. Construction: Core: Polyamide Reinforcement: Single steel wire braid Cover: Blue color Polyurethane and optional pin pricked. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH179 - SAE J517 100R14 SMOOTH BORE PTFE HOSE Application: P.T.F.E hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficent of friction and resists deterioration. Therefore the hose is used generally in applications where all are one of the above properties is the main criteria. Applicable Standard: Standard: SAE J517 – 100R14 Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH381 EXCEEDS SAE J517 / 100R14 SMOOTH BORE PTFE HOSE 2 W/B Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Applicable Standard: Standard: Exceeds SAE J517 – 100R14 pressure requirements. Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
