E-Catalog > Rubber Sheet And Gasket Ring,Back up Ring,Gland Packing > Rubber Sheet Mat.White NBR

  Air Filter Regulator Lubricator ชุดปรับปรุงคุณภาพลมอัดหรือ ชุดกรองปรับลม?เพื่อใช้ในงาน ระบบลมอัด เพื่อกรองสิ่งสรกปรก ปรับแรงดันลมให้เหมาะสมกับการใช้งาน และ จ่ายน้ำมันให้กับระบบเพื่อหล่อลื่นสิ้นส่วนต่างในระบบลมอัด

Air Control Valve ระบบนิวแมติก หรือ ระบบลมอัด จะทำงานได้ด้วยชุดกำเนิดลมอัดหรือปั้มลม จ่ายลมให้กับอุปกรณของระบบเพื่อทำงาน ดั่งนั้น ถ้าต้องการให้ระบบทำงานตามที่เราต้องการได้ก็ต้องมีการควบคุมทิศทางของลมอัด นั่นก็คือวาล์วต่างๆที่ใช้ในระบบ วาล์วต่างๆ นั้นมีหลายแบบขึ้นอยู่กับการใช้งาน เช่น วาล์วควบคุมทิศทางการไหลของลมอัด,วาล์วเปิดปิดเป็นต้น

HYDRAULIC HOSE FLEXOR 12 MSHA SAE 100 R12 - EN 856 R12 : WIRE SPIRAL - 898AA APPLICATION: VERY HIGH PRESSURE HYDRAULIC LINES, FUEL OIL, ANTIFREEZE SOLUTIONS, AIR AND WATER

PH148 - SAE 100R7 / DIN EN855 MEDIUM PRESSURE HYDRAULIC LINES 70 TO 210 BAR Application: Medium Pressure Hydraulic Lines 70 to 210 bar. Suitable for Hydraulic application with increased resistance to abrasion. For use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural machinery, Earthmoving, Articulating & Telescopic booms and Material handling equipments. Can be used for industrial gases and other applications, please consult manufacturer. Applicable Standard: tandard: SAE 100 R7 / DIN EN 855 Construction: Core: Thermoplastic Elastomer Reinforcement: 1 braid of synthetic fibre Cover: Black color, Pin Pricked – Polyurethane. Available twin and multi lines with different hose combination and size. Also, special colors up on request. Temperature Range: Continuous: -40°C to +100°C Temp. not to exceed +70°C for Air and Water based fluids

PH277 - SPIRAL HOSE. EN 856 / 4SP VERY HIGH PRESSURE HYDRAULIC LINES 165 TO 450 BAR Application: Very high pressure Hydraulic Lines 165 to 450 bar and hydrostatic transmission lines For use with petroleum, synthetic or water based fluids in Hydraulic systems Suitable for Earthmoving & Material handling equipments and machineries/systems Applicable Standard: Standard: EN 856-4SP Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID Application: Airless paint spray systems for 120 to 350 bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases. Applicable Standard: Standard: Polyhose proprietary Hose. Construction: Core: Polyamide Reinforcement: Single steel wire braid Cover: Blue color Polyurethane and optional pin pricked. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH179 - SAE J517 100R14 SMOOTH BORE PTFE HOSE Application: P.T.F.E hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficent of friction and resists deterioration. Therefore the hose is used generally in applications where all are one of the above properties is the main criteria. Applicable Standard: Standard: SAE J517 – 100R14 Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
