E-Catalog > Stainless Steel Flexible Hoses and Metal Hose:SUS304,SUS316 > Flexible Hoses Type.Union-Nipple

PH149 - SAE 100R8 / DIN EN855 HIGH PRESSURE HYDRAULIC LINES 100 TO 420 BAR Application: Highpressure Hydraulic Lines 100 to 420 bar. Compact, high pressure, light weight and low change in length. Suitable for hydraulic application with increased resistance to abrasion. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for Agricultural machinery, Earthmoving, Safety, Rescue and material handling equipments. Can be used for industrial gase and other applications, please consult manufacturer. Applicable Standard: Standard: SAE 100 R8 / DIN EN 855 Construction: Core: Thermoplastic Elastomer Reinforcement: 1 or 2 braid of Aramid fibre Cover: Black color, Pin Pricked – Polyurethane. Available twin and multi lines with different hose combination and size. Also, special colors up on request. Temperature Range: Continuous: -40°C to +100°C temp. not to exceed +70°C for Air and water based fluids.

PH253 - R1AT / 1SN- SAE J517-100R1AT / EN 853-1SN / ISO 1436 Applicable Standard : SAE J517-100R1AT / EN 853-1SN / ISO 1436 Construction Inner tube : Black Color, Synthetic rubber resistant to oil and water Reinforcement : Single steel wire braid Cover : Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozone. Available in wrap and smooth finish* Application : Medium Pressure Hydraulic Lines 10 to 250 bar. For use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agriculture, Earthmoving & Material handling equipment and machineries/systems Cover Options PH253: MSHA PH248: HARDX MSHA PH298: ABRAZONX MSHA Temperature Usage Options PH553: Low temperature -55°C to + 100°C PH255: High temperature MSHA cover -40°C to +135°C PH291: Ultra high temperature MSHA cover -40°C to +150°C Note : Sizes 2-1/2" to 4" are not covered under SAE J517-100R1AT/EN 853-1SN

PH154 - SAE J517-100-R2 / EN 853 2SN HIGH PRESSURE HYDRAULIC LINES 80 TO 415 BAR Application: High Pressure Hydraulic Lines 80 to 415 bar and requires compact outer dia. For use with petroleum, synthetic or water based fluids in Hydraulic systems Suitable for Agricultural, Earthmoving & Material handling equipments and machineries/systems. Applicable Standard: Standard: SAE J517 – 100 R2 / EN 853-2SN Construction: Core: Oil & water resistant Synthetic rubber Reinforcement: Double steel wire braids Cover: Black Color, Synthetic rubber resistant to weather and abrasion ,oil & ozone Temperature Range: Continuous: -40°C to +120°C Impulse Cycles : 200,000 Tested upto: 400,000 cycles,upto 1” I.D.

PH277 - SPIRAL HOSE. EN 856 / 4SP VERY HIGH PRESSURE HYDRAULIC LINES 165 TO 450 BAR Application: Very high pressure Hydraulic Lines 165 to 450 bar and hydrostatic transmission lines For use with petroleum, synthetic or water based fluids in Hydraulic systems Suitable for Earthmoving & Material handling equipments and machineries/systems Applicable Standard: Standard: EN 856-4SP Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID Application: Airless paint spray systems for 120 to 350 bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases. Applicable Standard: Standard: Polyhose proprietary Hose. Construction: Core: Polyamide Reinforcement: Single steel wire braid Cover: Blue color Polyurethane and optional pin pricked. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH179 - SAE J517 100R14 SMOOTH BORE PTFE HOSE Application: P.T.F.E hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficent of friction and resists deterioration. Therefore the hose is used generally in applications where all are one of the above properties is the main criteria. Applicable Standard: Standard: SAE J517 – 100R14 Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH381 EXCEEDS SAE J517 / 100R14 SMOOTH BORE PTFE HOSE 2 W/B Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Applicable Standard: Standard: Exceeds SAE J517 – 100R14 pressure requirements. Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C
