E-Catalog > Large Bore Industrial Hose: Hoses suitable for suction and discharge of gasoline and petroleum oils & bulk material dry cement, gravel, sand etc,. > LARGE BORE INDUSTRIAL HOSE PH642 XLPE CHEMICAL SUCTION AND DISCHARGE HOSE

รับผลิตงานสั่งทำงานยางทุกประเภท ผลิตและจำหน่าย อะไหล่ยางสำหรับอุตสาหกรรมทุกประเภท เน้นคุณภาพของชิ้นงานและวัตถุดิบประเภทยาง O-RING MADE TO ORDER:NBR,VITON,EPDM,SILICON

EPM, EPDM (Ethylene-Propylene Rubber): EPDM is not resistant to mineral oil based fluids and greases, synthetic hydrocarbon lubricants, organic ester based lubricants and hydrocarbon fuels. Temperature Range: -50°C To +150°C Chemicall Resistance: Hot water and steam (up to 150 °C) glycol based brake fluids organic and inorganic acids cleaning agents, soda and potassium alkalis phosphate-ester based hydraulic fluids polar sovents (Alcohol, Ketones, Esters) Ozone, Weather and Ageing Resistant Applications: Brake fluid components window profiles hot water applications Not compatible with: Mineral Oils

  Air Control Valve ระบบนิวแมติก หรือ ระบบลมอัด จะทำงานได้ด้วยชุดกำเนิดลมอัดหรือปั้มลม จ่ายลมให้กับอุปกรณของระบบเพื่อทำงาน ดั่งนั้น ถ้าต้องการให้ระบบทำงานตามที่เราต้องการได้ก็ต้องมีการควบคุมทิศทางของลมอัด นั่นก็คือวาล์วต่างๆที่ใช้ในระบบ วาล์วต่างๆ นั้นมีหลายแบบขึ้นอยู่กับการใช้งาน เช่น วาล์วควบคุมทิศทางการไหลของลมอัด,วาล์วเปิดปิดเป็นต้น

HYDRAULIC HOSE PH146 - SAE J517-100-R5 MEDIUM PRESSURE HYDRAULIC LINES 25 TO 210 BAR Application: MEDIUM Pressure Hydraulic Lines 25 to 210 bar. For use with fluids in Hydraulic systems Can also be used in air and water. Suitable for Agricultural, Earthmoving & Material handling equipments and machineries/systems Applicable Standard: Standard: SAE J517 – 100 R5 Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Single steel wire braid Cover: Black Color, single braid of textile fiber Temperature Range: Continuous: -40°C to +120°C

HYDRAULIC HOSE PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH381 EXCEEDS SAE J517 / 100R14 SMOOTH BORE PTFE HOSE 2 W/B Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Applicable Standard: Standard: Exceeds SAE J517 – 100R14 pressure requirements. Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
