Product Information :
Name :
NYLON PNEUMATIC TUBE Category :
- เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
- Flexible Industrial Hose:Teflon Hoses,Flexible PVC
Brand :
ASHUN Product Type :
- สินค้า, ผลิตภัณฑ์
Short Description :
Nylon Tube
● Excellent in weather resistance
● Good aging
● Resists abrasion and vibration
● High tensile strength and modulus of elasticity
● High impact resistance, a high heat distortion temperature
● Can withstand contact with chemicals, alkalis, dilute acids or oxidizing agents
Application
For Hydraulic Hoses, Robotics, and Vacuum, Fuel, Vapor, Air and Brake lines. Its Heat Resistance and UV Stabilization Make it Resistant to Stress-Cracking, So it Works Well in Sunny Areas.
Product Detail :
Nylon Tube
● Excellent in weather resistance
● Good aging
● Resists abrasion and vibration
● High tensile strength and modulus of elasticity
● High impact resistance, a high heat distortion temperature
● Can withstand contact with chemicals, alkalis, dilute acids or oxidizing agents
Application
For Hydraulic Hoses, Robotics, and Vacuum, Fuel, Vapor, Air and Brake lines. Its Heat Resistance and UV Stabilization Make it Resistant to Stress-Cracking, So it Works Well in Sunny Areas.
Description
| ITEM No. | OD | x | ID | x | Length (M) |
| (mm) | (mm) | ||||
| NYLON- 0425 | 4.00 | x | 2.50 | x | 200 M |
| NYLON- 0604 | 6.00 | x | 4.00 | x | 100 M |
| NYLON- 0806 | 8.00 | x | 6.00 | x | 100 M |
| NYLON- 1075 | 10.00 | x | 7.50 | x | 100 M |
| NYLON- 1209 | 12.00 | x | 9.00 | x | 100 M |
| NYLON- 4731 | 4.76 | x | 3.17 | x | 100 M |
| NYLON- 6345 | 6.35 | x | 4.57 | x | 100 M |
| NYLON- 9569 | 9.53 | x | 6.99 | x | 100 M |
| NYLON- 1295 | 12.70 | x | 9.56 | x | 100 M |
| PART NO. | OD x ID | BURST | WORKING PRESSURE | MIN. BENDING | STANDARD LENGTH | WEIGHT |
| (mm) | PRESSURE (Kgf/cm2) | (Kgf/cm2) | RADIUS | (M) | (g/m) | |
| (mm) | ||||||
| NYLON 0425 | 4.00x2.50 | 99.00 | <20 | 17.00 | 100.00 | 7.00 |
| NYLON 0604 | 6.00x4.00 | 66.00 | <20 | 37.00 | 100.00 | 15.00 |
| NYLON 0806 | 8.00x6.00 | 63.00 | <20 | 48.00 | 100.00 | 23.00 |
| NYLON 1075 | 10.00x7.50 | 67.00 | <20 | 66.00 | 100.00 | 35.00 |
| NYLON 1209 | 12.00x9.00 | 64.00 | <20 | 76.00 | 100.00 | 53.00 |
| NYLON 4731 | 4.76x3.17 | 67.00 | <20 | 22.00 | 100.00 | 8.00 |
| NYLON 6345 | 6.35x4.57 | 66.00 | <20 | 39.00 | 100.00 | 16.00 |
| NYLON 9569 | 9.53x6.99 | 63.00 | <20 | 65.00 | 100.00 | 40.00 |
| NYLON 1295 | 12.70x9.56 | 68.00 | <20 | 80.00 | 100.00 | 55.00 |
