E-Catalog > Pneumatic:Air Cylinder,Unit Services,Air Control Valve > Cylinder Accessories Joint อุปกรณ์ต่อร่วมกับกระบอกลม

PH624 - SHOT BLASTING HOSE W.P. 12 BAR - PH2 Application : Suitably designed long lasting heavy duty hose for use in sand, metal grits and foundry waste with conductive rubber compound to ensure static electricity dissipation abrasion loss of the tube according to ISO 4649: 50+5mm3 Cover Options PH674-PH1 : Premium abrasion

PH703-04, paint hose Automation Grade: Manual Automation Grade : Manual Product Type : Paint hose Usage/Application : Paint application Material : spary hose Grade : paint Pressure : 520 bar Capacity : 7540 psi Air Flow Pattern : paint Maximum Hydraulic Pressure : 520 bar Fluid Pressure : Paint Fluids : paint The most popular airless hose size is 1/4" by 50 foot. Large sprayers may require 3/8". If you are running 100' of hose, it is best to start with 50-foot 3/8" at the sprayer then connect a 50'. Protect your hose with a disposable hose cover.

PH144 - SAE J517 - 100 R3 / EN 854: Standard Hydraulic Hose – Rubber HYDRAULIC HOSE PH144 - SAE J517-100-R3 / EN 854 /LOW PRESSURE AND LOW IMPULSE HYDRAULIC LINES 30 TO 110 BAR Application: Low pressure and low impulse hydraulic lines 30 to 110 bar.for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural, Construction & Material handiling equipments and machineries/systems. Applicable Standard: Standard: SAE J517 – 100 R3 / EN 854 Construction: Core: Oil resistant Synthetic rubber Reinforcement: Double fiber braids Cover:Black Color, Synthetic rubber resistant weather and abrasion Temperature Range:Continuous: -40°C to +120°C PH144 - SAE J517 - 100 R3 / EN 854: สายไฮดรอลิกมาตรฐาน – ยาง สายไฮดรอลิก PH144 - SAE J517-100-R3 / EN 854 / สายไฮดรอลิกแรงดันต่ำและแรงกระตุ้นต่ำ 30 ถึง 110 บาร์ การใช้งาน: สายไฮดรอลิกแรงดันต่ำและแรงกระตุ้นต่ำ 30 ถึง 110 บาร์ สำหรับใช้กับน้ำมันปิโตรเลียม สังเคราะห์ หรือของเหลวที่ใช้กับน้ำในระบบไฮดรอลิก เหมาะสำหรับอุปกรณ์และเครื่องจักร/ระบบการจัดการวัสดุทางการเกษตร การก่อสร้าง และการจัดการวัสดุ มาตรฐานที่ใช้บังคับ: มาตรฐาน: SAE J517 - 100 R3 / EN 854 โครงสร้าง: แกนกลาง : ยางสังเคราะห์ทนน้ำมัน การเสริมแรง: เส้นใยคู่ถักเปีย ปลอก: สีดำ ยางสังเคราะห์ทนต่อสภาพอากาศและการขีดข่วน ช่วงอุณหภูมิ: ต่อเนื่อง: -40°C ถึง +120°C

PH149 - SAE 100R8 / DIN EN855 HIGH PRESSURE HYDRAULIC LINES 100 TO 420 BAR Application: Highpressure Hydraulic Lines 100 to 420 bar. Compact, high pressure, light weight and low change in length. Suitable for hydraulic application with increased resistance to abrasion. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for Agricultural machinery, Earthmoving, Safety, Rescue and material handling equipments. Can be used for industrial gase and other applications, please consult manufacturer. Applicable Standard: Standard: SAE 100 R8 / DIN EN 855 Construction: Core: Thermoplastic Elastomer Reinforcement: 1 or 2 braid of Aramid fibre Cover: Black color, Pin Pricked – Polyurethane. Available twin and multi lines with different hose combination and size. Also, special colors up on request. Temperature Range: Continuous: -40°C to +100°C temp. not to exceed +70°C for Air and water based fluids.

PH253 - R1AT / 1SN- SAE J517-100R1AT / EN 853-1SN / ISO 1436 Applicable Standard : SAE J517-100R1AT / EN 853-1SN / ISO 1436 Construction Inner tube : Black Color, Synthetic rubber resistant to oil and water Reinforcement : Single steel wire braid Cover : Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozone. Available in wrap and smooth finish* Application : Medium Pressure Hydraulic Lines 10 to 250 bar. For use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agriculture, Earthmoving & Material handling equipment and machineries/systems Cover Options PH253: MSHA PH248: HARDX MSHA PH298: ABRAZONX MSHA Temperature Usage Options PH553: Low temperature -55°C to + 100°C PH255: High temperature MSHA cover -40°C to +135°C PH291: Ultra high temperature MSHA cover -40°C to +150°C Note : Sizes 2-1/2" to 4" are not covered under SAE J517-100R1AT/EN 853-1SN

PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID Application: Airless paint spray systems for 120 to 350 bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases. Applicable Standard: Standard: Polyhose proprietary Hose. Construction: Core: Polyamide Reinforcement: Single steel wire braid Cover: Blue color Polyurethane and optional pin pricked. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
