E-Catalog > Industrial Hose: Hoses suitable for suction and discharge of gasoline and petroleum oils & bulk material dry cement, gravel, sand etc,. > PH624 - SHOT BLASTING HOSE W.P. 12 BAR - PH2

PH144 - SAE J517 - 100 R3 / EN 854: Standard Hydraulic Hose – Rubber HYDRAULIC HOSE PH144 - SAE J517-100-R3 / EN 854 /LOW PRESSURE AND LOW IMPULSE HYDRAULIC LINES 30 TO 110 BAR Application: Low pressure and low impulse hydraulic lines 30 to 110 bar.for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural, Construction & Material handiling equipments and machineries/systems. Applicable Standard: Standard: SAE J517 – 100 R3 / EN 854 Construction: Core: Oil resistant Synthetic rubber Reinforcement: Double fiber braids Cover:Black Color, Synthetic rubber resistant weather and abrasion Temperature Range:Continuous: -40°C to +120°C PH144 - SAE J517 - 100 R3 / EN 854: สายไฮดรอลิกมาตรฐาน – ยาง สายไฮดรอลิก PH144 - SAE J517-100-R3 / EN 854 / สายไฮดรอลิกแรงดันต่ำและแรงกระตุ้นต่ำ 30 ถึง 110 บาร์ การใช้งาน: สายไฮดรอลิกแรงดันต่ำและแรงกระตุ้นต่ำ 30 ถึง 110 บาร์ สำหรับใช้กับน้ำมันปิโตรเลียม สังเคราะห์ หรือของเหลวที่ใช้กับน้ำในระบบไฮดรอลิก เหมาะสำหรับอุปกรณ์และเครื่องจักร/ระบบการจัดการวัสดุทางการเกษตร การก่อสร้าง และการจัดการวัสดุ มาตรฐานที่ใช้บังคับ: มาตรฐาน: SAE J517 - 100 R3 / EN 854 โครงสร้าง: แกนกลาง : ยางสังเคราะห์ทนน้ำมัน การเสริมแรง: เส้นใยคู่ถักเปีย ปลอก: สีดำ ยางสังเคราะห์ทนต่อสภาพอากาศและการขีดข่วน ช่วงอุณหภูมิ: ต่อเนื่อง: -40°C ถึง +120°C

PH147 - SAE J517-100-R6 / EN 854 / VERY LOW PRESSURE AND LOW IMPULSE HYDRAULIC LINES 20 TO 35 BAR Application: Very low pressure and low impulse hydraulic lines 20 to 35 bar.for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural, Stationary equipments and hydraulic systems. Applicable Standard: Standard: SAE J517 – 100 R6 / EN 854 Construction: Core: Oil resistant Synthetic rubber Reinforcement: Single fiber braid Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +120°C

PH146 - SAE J517-100-R5 MEDIUM PRESSURE HYDRAULIC LINES 25 TO 210 BAR Application: MEDIUM Pressure Hydraulic Lines 25 to 210 bar. For use with fluids in Hydraulic systems Can also be used in air and water. Suitable for Agricultural, Earthmoving & Material handling equipments and machineries/systems Applicable Standard: Standard: SAE J517 – 100 R5 Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Single steel wire braid Cover: Black Color, single braid of textile fiber Temperature Range: Continuous: -40°C to +120°C

PH149 - SAE 100R8 / DIN EN855 HIGH PRESSURE HYDRAULIC LINES 100 TO 420 BAR Application: Highpressure Hydraulic Lines 100 to 420 bar. Compact, high pressure, light weight and low change in length. Suitable for hydraulic application with increased resistance to abrasion. For use with petroleum, synthetic or water based fluids in hydraulic systems. Suitable for Agricultural machinery, Earthmoving, Safety, Rescue and material handling equipments. Can be used for industrial gase and other applications, please consult manufacturer. Applicable Standard: Standard: SAE 100 R8 / DIN EN 855 Construction: Core: Thermoplastic Elastomer Reinforcement: 1 or 2 braid of Aramid fibre Cover: Black color, Pin Pricked – Polyurethane. Available twin and multi lines with different hose combination and size. Also, special colors up on request. Temperature Range: Continuous: -40°C to +100°C temp. not to exceed +70°C for Air and water based fluids.

PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID Application: Airless paint spray systems for 120 to 350 bar. Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases. Applicable Standard: Standard: Polyhose proprietary Hose. Construction: Core: Polyamide Reinforcement: Single steel wire braid Cover: Blue color Polyurethane and optional pin pricked. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH179 - SAE J517 100R14 SMOOTH BORE PTFE HOSE Application: P.T.F.E hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficent of friction and resists deterioration. Therefore the hose is used generally in applications where all are one of the above properties is the main criteria. Applicable Standard: Standard: SAE J517 – 100R14 Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH381 EXCEEDS SAE J517 / 100R14 SMOOTH BORE PTFE HOSE 2 W/B Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Applicable Standard: Standard: Exceeds SAE J517 – 100R14 pressure requirements. Construction: Core: Sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C
