E-Catalog > Large Bore Industrial Hose: Hoses suitable for suction and discharge of gasoline and petroleum oils & bulk material dry cement, gravel, sand etc,. > LARGE BORE INDUSTRIAL HOSE PH602 WATER DISCHARGE HOSE W/P.10 BAR. LAY FLAT

Oil Seal or Shaft Seal Type: TC, TB, TA, SC, SB, SA, VC, VB, VA, KC, KB, KA, DC Material: NBR,VITON.FPM.FKM,CR,VMQ,NR Rubber Usage: Engine, Transmission, Rear Axle Standard: Standard, Nonstandard Product Description: Rubber Oil Seal :Motor part, auto part, car part Good Resitance To Wearing Flexible And Easy To Assembly Good Hydraulic Proof Important Physical Properties : Hardness85 ShA -Working Temperature: -40~+100 -Working Pressure: ≤ 250bar TC (Double Lip Seal ซีลขอบยางสองลิป) SC (Single Lip ซีลขอบยางลิปเดียว) TB (Double Lip ซีลขอบเหล็กสองลิป) SB (Single Lip ซีลขอบเหล็กลิปเดียว) TCN-TA (Double Lip ซีลขอบเหล็กสองลิปแบบมีเหล็กปิดตูด)

Chevron Vee-Seal Vee Packing Series Consist of Three Parts,Which are Seal Ring, support Ring and Pressing Ring. It is the Seal used for Piston Rod of Tank.Vee Packings are Multiple-Lip (Chevron) Seals Comprised of a Group of Endless Rings and Popular for Sealing Rods and Pistons. They can be used for Low or High Pressure Applications and With Single or Double Acting Cylinders. Materials: Under the Weather of Below 100 Centigrade,V Packing Adopt NBR Fabric-Reinforced, Support Ring, Pressing Ring Adopt NBR Fabric-Reinforced or Nylon; Which can be in use 100-200 Centigraqde; V Packing Adopt PTFE, FKM, Pressing Ring and Support Ring Adopt PTFE.

FLEXEOR 1SN/R1AT ISO-1436–SEA 100R1AT/R1S Hydraulic Hose.single wire braid hydraulic hose on easy-to-handle reels-tr1sn.tr1sn-formerly t836aa/t836aa.single wire braid : meets or exceeds sae 100r1at-en853 1sn msha ic-152/8 approved. FLEXOR 2SN/R2AT ISO-1436-1–SEA 100 R2AT/R2S Hydraulic Hose.double wire braid hydraulic hose on easy-to-handle reels-tr2sn.tr2sn-formerly t846aa.double wire braid: meets or exceeds sae 100 r2at-en 853 2sn msha ic-152/8 approved tr2sn-formerly t841aa.double wire braid:Meets or exceeds sae 100r2a FLEXOR 3 SAE 100R3-EN854 R3–DN Hydraulic Hose.textile-reinforced hydraulic hose with two braids-tr3.tr3-formerly t870aa.two High tensile textile braids-meets or exceeds sae 100r3-en854 r3–dn FLEXOR 4SP SAE 100R12-EN 856 4SP and ISO 3862 Hydraulic Hose.four layer wire spiral reinforced hydraulic hose-t4sp.t4sp-formerly t850aa.four wire spiral :-meets or exceeds sae 100r12-en 856 4sp and iso 3862-meets flame resistance acceptance designation us msha ic-152/8 FLEXOR 5 SAE 100 R5 Hydraulic Hose.One-wire braid hydraulic hose-TR5.TR5-formerly t805aa One-wire braid-reinforced-Meets or exceeds sae 100 r5

Air Control Valve ระบบนิวแมติก หรือ ระบบลมอัด จะทำงานได้ด้วยชุดกำเนิดลมอัดหรือปั้มลม จ่ายลมให้กับอุปกรณของระบบเพื่อทำงาน ดั่งนั้น ถ้าต้องการให้ระบบทำงานตามที่เราต้องการได้ก็ต้องมีการควบคุมทิศทางของลมอัด นั่นก็คือวาล์วต่างๆที่ใช้ในระบบ วาล์วต่างๆ นั้นมีหลายแบบขึ้นอยู่กับการใช้งาน เช่น วาล์วควบคุมทิศทางการไหลของลมอัด,วาล์วเปิดปิดเป็นต้น

HYDRAULIC HOSE PH278 - SPIRAL HOSE. EN 856 / 4SH /VERY HIGH PRESSURE HYDR.LINES 250 TO 420 BAR Application: Very high pressure Hydraulic Lines 250 to 420 bar and hydrostatic transmission lines for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Eathmoving & Material handling equipemtns and machineries/systems. Applicable Standard: Standard: EN 856-4SH Construction: Core: Oil and Water resistant Synthetic rubber Reinforcement: Four high tensile steel wire spirals Cover: Black Color, Synthetic rubber resistant to oil, weather and abrasion Temperature Range: Continuous: -40°C to +100°C Intermittent: max. 120°C

THERMOPLASTIC HYDRAULIC HOSE PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR Application: Very High Pressure Hydraulic Lines 520 to 700 bar. Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments. Applicable Standard: Standard: Polyhose proprietary hose. Construction: Core: Thermoplastic Elastomer Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size. Temperature Range: Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.

TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Single braid of 304/316 series of stainless steel wire Temperature Range: Continuous: -54°C to +260°C

TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316 Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure. Applicable Standard: Standard: Polyhose proprietary product. Construction: Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.). Reinforcement: Double braids of 303/304 series of stainless steel wire Temperature Range: Continuous: -60°C to +260°C
