HYDRAULIC HOSE FLEXOR 4SP SAE 100R10 - EN856 4SP : WIRE SPIRAL - 850AA
APPLICATION : VERY HIGH PRESSURE HYDRAULIC LINES, FUEL OIL, ANTIFREEZE SOLUTIONS, AIR AND WATER.
E-Catalog > Large Bore Industrial Hose: Hoses suitable for suction and discharge of gasoline and petroleum oils & bulk material dry cement, gravel, sand etc,. > LARGE BORE INDUSTRIAL HOSE PH623 BULK MATERIAL SUCTION AND DISCHARGE HOSE
PAGE VIEW : 5,874
Product Information :
Name :
LARGE BORE INDUSTRIAL HOSE PH623 BULK MATERIAL SUCTION AND DISCHARGE HOSE Category :
- การบริการต่าง ๆ, การซ่อมบำรุง
Sub - Category :
- Large Bore Industrial Hose: Hoses suitable for suction and discharge of gasoline and petroleum oils & bulk material dry cement, gravel, sand etc,.
Brand :
POLYHOSE Product Type :
- สินค้า, ผลิตภัณฑ์
Short Description :
LARGE BORE INDUSTRIAL HOSE PH623 BULK MATERIAL SUCTION AND DISCHARGE HOSE
Application: For suction and discharge of bulk material dry cement, gravel, sand, etc., in construction industry.
Construction:
Core: Natural rubber blend reistant to abrasion.
Reinforcement: High tensile synthetic yarn with wire helix and copper wire.
Cover: Synthetic rubber resistant to ozone, oil, weather and abrasion.
Temperature Range:
Continuous: -30°C to +75°C.
Product Detail :
PH623 – BULK MATERIAL SUCTION AND DISCHARGE HOSE
LARGE BORE INDUSTRIAL HOSE PH623 BULK MATERIAL SUCTION AND DISCHARGE HOSE
Application: For suction and discharge of bulk material dry cement, gravel, sand, etc., in construction industry.
Construction:
Core: Natural rubber blend reistant to abrasion.
Reinforcement: High tensile synthetic yarn with wire helix and copper wire.
Cover: Synthetic rubber resistant to ozone, oil, weather and abrasion.
Temperature Range: Continuous: -30°C to +75°C.
Product Gallery :
Related Product :
HYDRAULIC HOSE FLEXOR 5 SEA 100R5 - J1402 DOT ALL FM VSS 106 : WIRE BRAID - 805AA
Application MEDIUM PRESSURE HYDRAULIC LINES, FUEL OIL, ANTIFREEZE SOLUTIONS, AIR AND WATER.
Air Cylinder กระบอกลม เพื่อใช้ในงาน ระบบลมอัด โดย มีให้เลือกตามความต้องการของลูกค้า กระบอกลมเป็นอุปกรณ์ ที่ใช้รับแรงกับชิ้นงานโดยตรง และ มีความสำคัญกับ ระบบ นิวแมติกส์โดยกระบอกลมจะเปลียนพลังลมเป็นพลังกล และจะเคลื่อนที่เป็นแนวตรงหรือในทิศทางการหมุนก็ได้(อุปกรณแรงบิด) กระบอกลมเข้ามามีบทบาทและความสำคัญในอุสาหกรรมอย่างมากเพาะการควบคุมที่ไม่ซับซ้อนรวมไปถึงการดูแลรักษาที่ไม่ยุ่งยากจึงถูกพัฒนาและใช้กันอย่างกว้างขวางในปัจจุบัน
Air Filter Regulator Lubricator ชุดปรับปรุงคุณภาพลมอัดหรือ ชุดกรองปรับลม?เพื่อใช้ในงาน ระบบลมอัด เพื่อกรองสิ่งสรกปรก ปรับแรงดันลมให้เหมาะสมกับการใช้งาน และ จ่ายน้ำมันให้กับระบบเพื่อหล่อลื่นสิ้นส่วนต่างในระบบลมอัด
THERMOPLASTIC PAINT SPRAY HOSE PH342 W/P.1.00 BAR AIRLESS PAINT SPRAY SYSTEMS FOR 120 TO 350 BAR - SINGLE STEEL WIRE BRAID
Application: Airless paint spray systems for 120 to 350 bar.
Suitable for applications requiring chemical resistance to solvents and aggressive fluids due to low permeation value of polyamide, the hose is also suitable for industrial gases.
Applicable Standard: Standard: Polyhose proprietary Hose.
Construction:
Core: Polyamide
Reinforcement: Single steel wire braid
Cover: Blue color Polyurethane and optional pin pricked.
Temperature Range:
Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.
THERMOPLASTIC HYDRAULIC HOSE PH350 / PH351 VERY H/P JACK HOSE HYDRAULIC LINES 520 TO 700 BAR
Application: Very High Pressure Hydraulic Lines 520 to 700 bar.
Compact, high pressure, light weight, high abrasion resistance and low change in length for use with petroleum, synthetic or water based fluids in Hydraulic Systems mainly used for rescue, safety equipments, bolt tensioning tools and jacking & re-railing equipments. Also, suitable for earthmoving and material handling equipments.
Applicable Standard: Standard: Polyhose proprietary hose.
Construction:
Core: Thermoplastic Elastomer
Reinforcement:PH350 Double steel wire braids, PH351 Single/Double braids of aramid fibre with single steel wire braid
Cover:Red/Orange color Polyurethane, Available Twin & Multi lines with different Hose combination and size.
Temperature Range:
Continuous: -40°C to +100°C Temp not to exceed +70°C for Air and water based fluids.
TEFLON (PTFE) HOSE PH370 CONVOLUTED / PH371 CONVOLUTED CONDUCTIVE
Aplication: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria in automotive, chemical, pharmaceutical & food processing, plastic & rubber molding machines. Also, for some applications the tube can also be made conductive to dissipate electro-static Charges.
Applicable Standard: Standard: Polyhose proprietary product.
Construction:
Core: Helically convoluted sintered tube of polytetrafluoroethylene (P.T.F.E.).
Reinforcement: Single braid of 304/316 series of stainless steel wire
Temperature Range:
Continuous: -54°C to +260°C
TEFLON (PTFE) HOSE PH382 GAS HOSE - DOUBLE BRAID OF SUS 304/316
Application: P.T.F.E. hose has an excellent temperature characteristics both in high and low temperature, Excellent chemical resistance, non contamination properties, low coefficient of friction and resists deterioration. Therefore the hose is used generally in applications where all or one of the above properties is the main criteria. Transport of cryogenic gases at high pressure.
Applicable Standard: Standard: Polyhose proprietary product.
Construction:
Core: Special quality of sintered tube of polytetrafluoroethylene (P.T.F.E.).
Reinforcement: Double braids of 303/304 series of stainless steel wire
Temperature Range:
Continuous: -60°C to +260°C
